1000W Aluminum Housed Wirewound Resistor with 1Ω-1000Ω Range ±5% Tolerance and ISO9001 Certification

Place of Origin : Sichuan, China

Brand Name : Bonens

Model Number : RIG42

MOQ : 100

Resistance range : 1Ω-500Ω

Resistance tolerance : ±5%

Frequency range : 0~2GHz

Standing wave ratio : 1.2~1.3

Insulation resistance : ≥ 1GΩ

Withstand voltage : 500V/1 mm

Terminal strength : 10N, 5S

Solderability : 240℃, 3s

Rated power : 20W-1000W (70°C)

Temperature range : -55°C~+165°C

TCR : ≤±150PPM/°C

Temperature shock : ΔR≤±5%R

Moisture proof : ΔR≤±5%R

Vibration resistance : ΔR≤±3%R

Load life : ΔR≤±5%

Contact Now

Product Description
1000W Aluminum Housed Wirewound Resistor with 1Ω-1000Ω Range ±5% Tolerance and ISO9001 Certification
Product features and uses
1. Small size. Large power capacity. Good high frequency characteristics. Stable performance* Easy installation. 2. Suitable for power divider, W isolation resistance and terminal load resistance in high-frequency circuits, such as in cavity couplers. Combiner. Duplexer: TV and FM transmitter. Stb. Hair generator. Base station antenna.3G. smart antenna, etc Widely used in aviation. Space flight. Radar. Radio station. Broadcasting and communication and other equipment fields.
1000W Aluminum Housed Wirewound Resistor with 1Ω-1000Ω Range ±5% Tolerance and ISO9001 Certification
1000W Aluminum Housed Wirewound Resistor with 1Ω-1000Ω Range ±5% Tolerance and ISO9001 Certification
1000W Aluminum Housed Wirewound Resistor with 1Ω-1000Ω Range ±5% Tolerance and ISO9001 Certification
1000W Aluminum Housed Wirewound Resistor with 1Ω-1000Ω Range ±5% Tolerance and ISO9001 Certification
1000W Aluminum Housed Wirewound Resistor with 1Ω-1000Ω Range ±5% Tolerance and ISO9001 Certification
1000W Aluminum Housed Wirewound Resistor with 1Ω-1000Ω Range ±5% Tolerance and ISO9001 Certification
1000W Aluminum Housed Wirewound Resistor with 1Ω-1000Ω Range ±5% Tolerance and ISO9001 Certification
1000W Aluminum Housed Wirewound Resistor with 1Ω-1000Ω Range ±5% Tolerance and ISO9001 Certification
1000W Aluminum Housed Wirewound Resistor with 1Ω-1000Ω Range ±5% Tolerance and ISO9001 Certification
Electrical Characteristics


Range of nominal resistance----- 1Ω-500ΩResistance tolerance-------------- ±5%
Frequency range------------------ 0~2GHz
Standing wave ratio-------------- 1.2~1.3
Insulation resistance-------------- ≥ 1GΩ
Withstand voltage---------------- 500V/1 mm (Substrate thickness)
1000W Aluminum Housed Wirewound Resistor with 1Ω-1000Ω Range ±5% Tolerance and ISO9001 Certification
1000W Aluminum Housed Wirewound Resistor with 1Ω-1000Ω Range ±5% Tolerance and ISO9001 Certification
Physical Characteristics


Terminal strength(10N,5S)------- No loose and fall off
Solderability(240℃,3s)--------Tin layer Covering area of 95%
Specification
Rated power
20W-1000W (70°C)
Temperature range
-55°C~+165°C
TCR
≤±150PPM/°C
Temperature shock (-55°C/+125°C, 3 times)
ΔR≤±5%R
Moisture proof (GJB306A-96-Method106)
ΔR≤±5%R
Vibration (10-500HZ, 0.75mm, 6h)
ΔR≤±3%R, No mechanical damage
Test at low temperature (-55°C, 24h)
ΔR≤±5%R
Load life (96)
ΔR≤±5%
Collision
ΔR≤±3%R
Packing & Delivery
1000W Aluminum Housed Wirewound Resistor with 1Ω-1000Ω Range ±5% Tolerance and ISO9001 Certification
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
1000W Aluminum Housed Wirewound Resistor with 1Ω-1000Ω Range ±5% Tolerance and ISO9001 Certification
1000W Aluminum Housed Wirewound Resistor with 1Ω-1000Ω Range ±5% Tolerance and ISO9001 Certification
1000W Aluminum Housed Wirewound Resistor with 1Ω-1000Ω Range ±5% Tolerance and ISO9001 Certification
1000W Aluminum Housed Wirewound Resistor with 1Ω-1000Ω Range ±5% Tolerance and ISO9001 Certification
1000W Aluminum Housed Wirewound Resistor with 1Ω-1000Ω Range ±5% Tolerance and ISO9001 Certification
1000W Aluminum Housed Wirewound Resistor with 1Ω-1000Ω Range ±5% Tolerance and ISO9001 Certification
Sichuan Qixing Electronics Co., Ltd. is specialized in manufacturing high-power resisters, wire-wound potentiometers, trimmer potentiometers, rotary carbon potentiometers, precision parts and so on ...... Engaged in civil and war industrial products for many years, we enfore ISO9001, ISO2000 quality control systems strictly. Our products are widely used in electronic communication products, instrument measuring appliances, cable TV equipments, electrician products, color television, color console, video and audio products and many other products. In order to maintain a leading position in the industry, we have further strengthened our product development ability. Moreover, we took the lead in introducing the world leading high temperature polymerization furnaces from the USA to establish ceramic resistance element production line. QIXING has 500 workers at present, among whom we are proud of our 56 professionals(35 of them got over 10 years' experience in potentiometer/ high-power resister). To satisfy our customers' needs, we provide product design and developing servises, OEM services, best aftersales servises and give best support once customer got a new idea. Providing massive acknowledged products to the war and civil industry units, our company has made certain
contribution to the motherland national defense and the thriving of our economy. "Technical innovation, striving for perfection, keeping on improving, continuously satisfying customers" is our company's quality policy, and "let customers be satisfied completely" is our goal. All our staff members are zealously creating a magnificent tomorrow with wit and diligence!
FAQ
1. who are we?
We are based in Sichuan, China, start from 2005,sell to Domestic Market(70.00%),Western Europe(8.00%),North America(5.00%),South
Asia(3.00%),Eastern Asia(3.00%),South America(2.00%),Southern Europe(2.00%),Eastern Europe(2.00%),Mid East(2.00%),Southeast
Asia(2.00%),Oceania(1.00%). There are total about 51-100 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Potentiometer , Resistor, EMI Filter, Knob, Switch

4. why should you buy from us not from other suppliers?
Our company is establsihed in 2005 ,which mainly develops and manufactures different types of potentiometer,ac dc noise filter,
and ceramic power resistor and is a professional manufacturer ensuring high quality, best services and best price.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,MoneyGram,Western Union,Cash;
Language Spoken:English,Chinese
